Sealed 12-Way Housing for MX150 Harness Builds
The 3.50mm pitch and dual-row layout match the standard MX150 header footprint, while the gray polyamide (PA6, glass-filled) body carries the latch holder that locks the pair together against vibration.
What the Sealed Rating Means for the Build
The housing is listed as sealed — this means the connector assembly, when mated with the matching MX150 header and fitted with the correct wire seals and crimp terminals, meets the IP6K9K / IP67 requirements typical of underhood and splash-zone automotive harnesses. The latch holder provides the secondary lock that keeps the interface closed under the 125°C upper limit; without it, the seal can unseat during thermal cycling.
This receptacle accepts female socket contacts (sold separately) terminated via crimp tooling — the 160111 series uses the standard MX150 terminal family.
