Molex Super Sabre 172042 series, 1720420301, 3-position single-row straight header, 7.50 mm pitch, male blade connector, through-hole solder mount, rated 30 A per circuit at 600 V, silver-plated copper contacts, finger-proof black housing with locking ramp, operating -40°C to 125°C.
| Parameter | Value |
|---|---|
| Series | Super Sabre 172042 |
| Mounting | Through Hole |
| Connector type | Header, Male Blades |
| Fastening type | Locking Ramp |
| Voltage rating | 600 V |
| Current rating | 30 A |
| Operating temperature | -40°C ~ 125°C |
| Color | Black |
| Contact material | Copper |
| Material - insulation | Liquid Crystal Polymer (LCP), Glass Filled |
| Pitch | 0.295\" (7.50mm) |
| Package | Tray |
| Features | Finger-Proof |
| Termination | Solder |
| Contact finish | Silver |
| Rows | 1 |
| Positions | 3 |
| Contact finish thickness | 100.0µin (2.54µm) |
The Molex Super Sabre 1720420301 is a 3-position single-row straight header from the Super Sabre 172042 series. The housing is finger-proof, which means the live blade tips are shrouded when unmated — a safety detail for service access.
The 30 A per circuit carries bus-level current. Silver plating at 100.0 µin supports repeated mating cycles.
The 1720420301 is sourced to order against an RFQ through independent distribution. Availability and current pricing are confirmed at quote time — submit an RFQ for your target quantity.
The 1720430206 (2-position) and 1720430606 (6-position) share the same 7.50 mm pitch, 30 A rating, silver plating, and locking ramp. They are position-count variants in the same Super Sabre family, not drop-in replacements — the 3-position 1720420301 is the direct match for a 3-circuit BOM line.
