Molex Mini-Fit Jr 172448 header, order code 1724481002, 2 positions, dual row, 4.20 mm pitch, gold-plated mating contacts, through-hole right-angle, solder termination, shrouded - 4 wall, locking ramp.
| Parameter | Value |
|---|---|
| Series | Mini-Fit Jr 172448 |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.378\" (9.60mm) |
| Insulation material | Polyamide (PA), Nylon |
| Material flammability rating | UL94 V-2 |
| Style | Board to Cable/Wire |
| Features | Board Lock, Glow Wire Compliant |
| Parameter | Value |
|---|---|
| Package | Tray |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose, Industrial, Telecommunications |
| Contact shape | Square |
| Rows | 2 |
| Positions | 2 |
| Row spacing - mating | 0.165\" (4.20mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.142\" (3.60mm) |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 1724481002 is the 2-circuit member of Molex's Mini-Fit Jr 172448 shrouded header line, designed for board-to-wire power distribution. Gold-plated mating contacts, a locking ramp, and glow-wire compliant housing suit it for industrial and telecom equipment where connection security under vibration is required.
RoHS and REACH documentation is provided by Molex.
