Molex 1727040063

Molex 1727040063 FCT D-Sub Plug, 15-Pin Solder Cup, 5A

MPN 1727040063
Active

Molex F, FCT 172704 D-Sub plug, 15 positions, 2 rows, male pins, solder cup termination, gold contacts, 5A, free hanging, white PBT housing, steel shell with grounding indents.

$5.6400 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
RoHSROHS3 Compliant
IncotermsDAP / DDP Available
SeriesF, FCT 172704
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1727040063 key specifications
ParameterValue
SeriesF, FCT 172704
TypeSignal
MountingFree Hanging (In-Line)
Connector typePlug, Male Pins
Current rating5A
Wire gauge20 AWG
Shell size, connector layout2 (DA, A)
Operating temperature-55°C ~ 125°C
ColorWhite
Contact materialBrass
Dielectric materialPolybutylene Terephthalate (PBT)
Shell material, finishSteel, Tin Plated

All specifications

1727040063 additional specifications
ParameterValue
PackageBulk
FeaturesGrounding Indents
TerminationSolder Cup
Contact finishGold
Flange featureHousing/Shell (Unthreaded)
Rows2
Positions15

Product details

15-Pin Male D-Sub Plug, Solder Cup Termination

The Molex 1727040063 is a 15-position male D-Sub plug from the F, FCT 172704 series, terminated via solder cup — not crimp — making it a field-serviceable choice for point-to-point wiring where the harness builder solders each conductor directly into the contact cup.

Solder Cup vs Crimp — What the Termination Tells You

The 1727040063 terminates via solder cup, not a crimp barrel. That means each wire is tinned and soldered into the cup on the back of the pin — a method that gives the harness builder full control over the solder joint quality and lets them replace a single contact without a special crimp tool. The trade-off is assembly time: a crimp D-Sub can be wired with a pneumatic press in seconds per contact; a solder-cup plug like this one takes longer per joint but is rework-friendly in a prototype or low-volume build. The wire gauge is specified for 20 AWG, which is the typical size for signal wiring in a D-Sub harness.

The base product number is 172704, which covers the FCT D-Sub family; the full 1727040063 suffix specifies the 15-position male plug with solder cup termination.

The connector layout is 2 (DA, A), which is the standard 15-pin D-Sub footprint — mates with any standard DA-15 female receptacle. The shell size is DA, and the flange feature is housing/shell with unthreaded holes, so it accepts a standard D-Sub slide-lock or screw-lock hardware kit for panel mounting. The free-hanging (in-line) mounting type means it is designed for cable-to-panel or cable-to-cable connections, not direct PCB mounting — the solder cups exit the back of the plug and the cable exits through the hood.
