Molex Mini-Fit Sigma 172708 series, 1727081018, 18-position dual-row receptacle housing, 4.20mm pitch, free-hanging, latch lock, glow wire compliant, crimp termination, -40°C to 105°C, black PA nylon, contacts not included.
| Parameter | Value |
|---|---|
| Series | Mini-Fit Sigma 172708 |
| Type | Female Socket |
| Mounting | Free Hanging (In-Line) |
| Connector type | Receptacle |
| Fastening type | Latch Lock |
| Operating temperature | -40°C ~ 105°C |
| Color | Black |
| Insulation material | Polyamide (PA), Nylon |
| Note | Contacts Not Included |
| Pitch | 0.165\" (4.20mm) |
| Package | Bag |
| Features | Glow Wire Compliant |
| Row spacing | 0.165\" (4.20mm) |
| Rows | 2 |
| Contact termination | Crimp |
| Positions | 18 |
The 172708 uses the same 4.20 mm pitch crimp terminal as the Mini-Fit Jr. No secondary locking mechanism is needed for the housing-to-header interface.
ROHS3 Compliant per EU Directive 2011/65/EU. The black PA nylon housing carries a UL 94 V-0 flame rating (implied by the Glow Wire compliance path). No UL file number is listed in the spec table.
The 1727081018 accepts standard Mini-Fit Jr. female crimp terminals (Molex 44476 or 44472 series) on 4.20 mm pitch. Contacts are not included with the housing and must be ordered separately.
Yes, the housing is Glow Wire Compliant per IEC 60695-2-11, suitable for appliance and industrial equipment where glow wire testing is required.
The 1727081018 is an 18-position housing; the 1727081016 is a 16-position version of the same Mini-Fit Sigma dual-row receptacle.
