Molex Mini-Fit Sigma 172767, 12-position plug housing, 4.20mm pitch, dual-row, 0.185" row spacing, panel mount snap-in, locking ramp, glow wire compliant, black PA nylon, -40 to 105°C.
| Parameter | Value |
|---|---|
| Series | Mini-Fit Sigma 172767 |
| Type | Male Pin |
| Mounting | Panel Mount, Snap-In |
| Connector type | Plug |
| Fastening type | Locking Ramp |
| Operating temperature | -40°C ~ 105°C |
| Color | Black |
| Insulation material | Polyamide (PA), Nylon |
| Note | Contacts Not Included |
| Pitch | 0.165\" (4.20mm) |
| Package | Bag |
| Features | Glow Wire Compliant |
| Row spacing | 0.185\" (4.70mm) |
| Rows | 2 |
| Contact termination | Crimp |
| Positions | 12 |
The Molex 1727673012 is the 12-circuit plug housing in the Mini-Fit Sigma 172767 series, designed for wire-to-wire and wire-to-board power applications where a secure, vibration-resistant connection is needed. The 4.20mm pitch and dual-row layout with 0.185" row spacing provide a compact yet robust footprint for power distribution in harness assemblies.
The panel-mount, snap-in feature allows tool-less installation into a cutout.
No — the listing explicitly states Contacts Not Included. The male crimp pins must be ordered separately from the Mini-Fit Sigma terminal family.
Yes — the housing carries a Glow Wire Compliant feature, making it suitable for appliance and IEC 60335 applications where glow-wire testing is required.
