2012010022 — Molex product photo
Molex

Molex 2012010022 Header, 2-Pos 2.00mm, Spot-On 2.0

MPN2012010022
Active

Molex Spot-On 2.0 header, order code 2012010022, 2 positions, single row, 2.00 mm pitch, 250 V, tin-plated mating contacts, surface-mount, solder termination.

$0.3907Ref. price · indicative, final on quote
2012010022 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

2012010022 Technical Specifications
ParameterValue
SeriesSpot-On 2.0 201201
GenderMale Pin
Mounting typeSurface Mount
Connector typeHeader
Fastening typeLatch Holder
Voltage rating250V
Current ratingVaries by Wire Gauge
Operating temperature-40°C ~ 105°C
Contact materialBrass
Insulation colorRed
Insulation height0.354\" (9.00mm)
Insulation materialPolyamide (PA), Nylon, Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageTape & Reel (TR)
FeaturesSolder Retention
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsGeneral Purpose
Contact shapeSquare
Rows1
Pitch0.079\" (2.00mm)
Positions2
Contact finish - postTin
Contact finish - matingTin
Contact finish thickness - post39.4µin (1.00µm)
Contact finish thickness - mating39.4µin (1.00µm)

Product details

2.00 mm pitch, 2-circuit, shrouded header

The 2012010022 is the 2-circuit member of Molex's Spot-On 2.0 201201 header line, a single-row shrouded board-to-wire connector.

Shroud, latch, and solder retention

The 4-wall shrouded housing with latch holder protects the pins during mating and resists vibration-induced disconnection. Solder retention features on the SMT tails improve board-level hold during reflow and handling.

Active production, single-source line

Molex lists the 2012010022 as Active.
