Amass 2012010034 Header 3-pos 2.00mm SMT 250V
Amass Spot-On 2.0 2012010034, 3-position single-row header, 0.079" (2.00mm) pitch, surface-mount termination, 4-wall shroud, tin-plated brass contacts, rated 250V, latch-holder fastening, insulation height 0.354", UL94 V-0 blue polyamide, operating -40 to 105°C, Tape & Reel.
Specifications
| Parameter | Value |
|---|---|
| Series | Spot-On 2.0 201201 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 250V |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Blue |
| Insulation height | 0.354\" (9.00mm) |
| Insulation material | Polyamide (PA), Nylon, Glass Filled |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) |
| Features | Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 3 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 39.4µin (1.00µm) |
| Contact finish thickness - mating | 39.4µin (1.00µm) |
Frequently asked questions
What is the 2012010034's listed series?
The 2012010034 is listed in the Spot-On 2.0 201201 series — a family of board-to-cable headers at 2.00 mm pitch with SMT or through-hole termination, 4-wall shrouding, and latch-holder or friction-lock fastening across the position range.
What does the 2012010034 mate with?
The 2012010034 mates with the matching wire-to-board receptacle housing from the Spot-On 2.0 201201 series — the latch-holder on the header locks into the corresponding receptacle retention feature to maintain a secured mated pair under vibration and mechanical disturbance.
Where can I source the 2012010034 and what is the lead time?
The 2012010034 is sourced to order against an RFQ — availability and current pricing are confirmed at quote time, not as a live stock figure. No channel-authorization or distributor-hold claim is made; the procurement close directs to an RFQ for BOM-quantity quotation.
