Shroud and latch details
The 2012010093: A 4-wall shrouded housing with a latch holder protects the pins and locks the mating half; the 0.354" (9.00 mm) insulation height and solder retention feature hold the header steady during reflow.
Molex 2012010093 Spot-On 2.0 Header, 9 Pos, 2.00mm
MPN2012010093
Active
Molex Spot-On 2.0 201201 header, order code 2012010093, 9 positions, single row, 2.00 mm pitch, 250 V, tin-plated mating contacts, surface-mount, solder termination, shrouded - 4 wall.
$0.6063Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Spot-On 2.0 201201 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 250V |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Yellow |
| Insulation height | 0.354\" (9.00mm) |
| Insulation material | Polyamide (PA), Nylon, Glass Filled |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) |
| Features | Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 9 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 39.4µin (1.00µm) |
| Contact finish thickness - mating | 39.4µin (1.00µm) |
Product details
Frequently asked questions
What compliance documentation does Molex provide for 2012010093?
RoHS and REACH compliance data is available from Molex on request.
