Molex CP-6.5 203555 two-piece connector header, 2 positions, dual-row, 6.50 mm row spacing, right-angle surface-mount, shrouded four-wall, tin-plated copper alloy tabs, rated 600VAC/DC, operating -40°C to 105°C, UL94 V-0 polyamide insulator.
- New & original stockTraceable channels only — no mixed lots, no re-taped reels.
- Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
- Photo-verified countsEvery line counted and photographed before the box closes.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | CP-6.5 203555 |
| Gender | Tab |
| Mounting type | Surface Mount, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 600VAC/DC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Red |
| Insulation height | 0.602\" (15.29mm) |
| Insulation material | Polyamide (PA), Nylon |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Board Guide, Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose, Industrial |
| Contact shape | Rectangular |
| Rows | 2 |
| Positions | 2 |
| Row spacing - mating | 0.256\" (6.50mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
Sourcing this connector
Molex 2035552022 is available through IC Source Direct’s Shenzhen interconnect channel. Submit an RFQ with your required quantity and timeline; we return a firm quote covering MOQ, lead time, condition, and unit price — typically within one business day.
Need a match by specification instead of MPN? Provide pitch, pin count, current rating, mounting style, and operating temperature. We cross-reference against Molex and other authorised lines, returning datasheet-verified alternatives. Attach a full BOM for multi-brand consolidation into one shipment.
Frequently asked questions
What replaces the 2035552022 if it goes NRND?
No official successor or cross-reference order code appears in the available record. The 203555-2022 is the same series member with an identical spec sheet but ships in a Box package instead of Tape & Reel.
Does the 2035552022 mate with the same housing as the 203555-2022?
Both are the 2-circuit member of the CP-6.5 203555 series — they share the same dual-row, 0.256-inch spacing and latch-holder fastening, so they mate with the same CP-6.5 series receptacle housing and accept the same wire gauge range.
What voltage and temperature range does the 2035552022 carry?
Rated 600VAC/DC continuous and operating from -40°C to 105°C — the range covers most Class B and Class F industrial and infrastructure equipment environments.
What compliance ratings does the 2035552022 carry?
The insulator is rated UL94 V-0; no separate RoHS, REACH, or UL recognition number is listed on this spec sheet.
