8-Position Micro-Lock PLUS Receptacle Housing, 1.25mm Pitch
The Molex 2045320801 is an 8-circuit receptacle housing from the Micro-Lock PLUS 204532 series, built on a 1.25mm pitch in a single-row layout. It is a free-hanging (in-line) housing with a latch holder for positive retention — the latch locks audibly when mated with the matching Micro-Lock PLUS plug header, giving a vibration-resistant connection suited for automotive and industrial harnesses where the cable sees movement.
Contacts Not Included — Order Separately
The listing explicitly notes contacts are not included. This is a bare housing — you order the female socket crimp terminals separately, then terminate them to the specified wire gauge and insert into the housing cavities.
Active Production, ROHS3 Compliant
No end-of-life notice or successor part is listed — it remains a current-production Molex catalog item.
