20-Position CONNTAK50 Receptacle for Sealed Harness Applications
The Molex 2058264201 is a 20-circuit, dual-row receptacle from the CONNTAK50 205826 series, designed for wire-to-wire or wire-to-panel interconnect in environments that demand a sealed, vibration-resistant connection. The 1.80mm pitch and 0.059" row spacing pack 20 positions into a compact body, while the panel mount snap-in feature lets you fix the receptacle directly to a panel cutout — no separate bracket or hardware. Crimp termination (female socket contacts) means the receptacle itself is the housing half — you crimp terminals onto the wire ends, insert them into the cavity, and the latch holder secures the mating plug.
The 2058264201 receptacle mates with the CONNTAK50 plug housing (the male half of the series). For wire termination, the female socket contacts accept the crimp terminals specified for the CONNTAK50 205826 series; typical wire gauge range for this series is 20-22 AWG, though the exact terminal part number and wire range should be confirmed against the mating terminal's datasheet for your specific strand count and insulation diameter.
