Molex Micro-One 205971 series, 2059710081, 2.00 mm pitch, 8-position single-row shrouded header, surface mount, latch lock, tin-bismuth contacts, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | Micro-One 205971 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Latch Lock |
| Voltage rating | 250VAC/DC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.390\" (9.90mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Cut Tape (CT) Bulk |
| Features | Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose, Industrial |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 8 |
| Contact finish - post | Tin-Bismuth |
| Contact finish - mating | Tin-Bismuth |
| Contact finish thickness - post | 39.4µin (1.00µm) |
| Contact finish thickness - mating | 39.4µin (1.00µm) |
Molex 2059710081 is an 8-position, single-row shrouded header from the Micro-One 205971 series.
The 4-wall shrouding guides the mating housing onto the pins and protects the contacts during handling and insertion.
For a given application, select the terminal rated for the required current and confirm the wire gauge matches.
ROHS3 compliant.
Molex 2059710081 is available to order through our distribution channel.
The 2059710081 header mates with a Micro-One 205971 series receptacle housing. The mating half uses crimp terminals — the current rating depends on the wire gauge selected.
