Sealed 18-Circuit Power Interconnect Housing
The Molex 2070170018 is an 18-circuit plug housing from the Mini-Fit Sigma 207017 series, designed for sealed wire-to-board or wire-to-wire power interconnects.
Sealing and Retention in a Vibration Environment
This housing is listed as sealed, which means the interface between the plug and its mating receptacle is protected against moisture and dust ingress when properly mated with the corresponding seal-capable header. The locking ramp fastening type provides an audible and tactile latching that resists un-mating under vibration — a common requirement for automotive harnesses, off-road equipment, and industrial machinery where a loose connector means a faulted circuit. The panel mount, snap-in mounting type allows the housing to be secured to a panel cutout before the wire harness is attached, simplifying assembly in tight enclosures.
Crimp Termination and Contact Compatibility
The 2-row, 18-position layout means the wire bundle exits in a single plane, which helps with routing in a harness tray or along a frame rail.
