Molex 2137192070 — Connector Housings

Molex Micro-Lock PLUS 2137192070, 7-Position Plug Housing

MPN2137192070
Active

Molex Micro-Lock PLUS 213719 series, 2137192070, 7-position single-row plug housing, 2.00mm pitch, crimp termination, locking ramp, free-hanging, natural PA nylon, -40°C to 105°C.

$0.7300Ref. price · indicative, final on quote
Molex 2137192070 datasheet (PDF)
RoHSROHS3 Compliant
SeriesMicro-Lock PLUS 213719
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

2137192070 specifications
ParameterValue
SeriesMicro-Lock PLUS 213719
TypeMale Pin
MountingFree Hanging (In-Line)
Connector typePlug
Fastening typeLocking Ramp
Operating temperature-40°C ~ 105°C
ColorNatural
Insulation materialPolyamide (PA), Nylon, Glass Filled
Pitch0.079\" (2.00mm)
PackageBag
Rows1
Contact terminationCrimp
Positions7

Product details

7-Position Plug Housing for Wire-to-Board Harnesses

Temperature Range and Material Choice

The natural colour is un-pigmented resin — no dye additives that could outgas or degrade in high-humidity environments. ROHS3 compliance is on record, which covers the full substance restriction list including the four phthalates.

This plug housing accepts male pin contacts (sold separately) terminated via standard crimp tooling for the Micro-Lock PLUS contact family. The free-hanging (in-line) mounting lets the plug float relative to the board, which helps absorb tolerance stack in multi-wire harnesses.

Frequently asked questions

What is the mating header for Molex 2137192070?

The 2137192070 mates with a Molex Micro-Lock PLUS single-row header of the same 2.00 mm pitch and 7-circuit count, featuring the matching locking ramp profile. The header part number depends on the mounting style (through-hole or SMT) and plating grade required for the application.

What is the pitch of Molex 2137192070?

The pitch is 2.00 mm (0.079"), single-row layout with 7 positions. This pitch is standard for the Micro-Lock PLUS series and matches the corresponding header footprint.
