Power-Delivery Plug for High-Current PCB Interfaces
The Molex 2141130010 is a 38-position, 5-row right-angle through-hole male blade plug from the EXTreme Guardian 214113 series. It is designed as a board-to-wire power interconnect — the male blades mate with a corresponding receptacle housing carrying crimped power terminals. The 38 positions break down as a ground-signal-ground-signal-ground pattern per the description "G+8P+30S+G P" — eight power circuits and thirty signal circuits, with ground blades flanking the signal group.
80 A per circuit is the headline number, but the real-world current depends on how many circuits are loaded simultaneously and the ambient temperature. The push-pull fastening means the connector is held by friction and a positive latch on the receptacle side — no screw-lock or jack-screw. The board guide and mating guide features on the housing help align the plug during blind-mate assembly, protecting the blades from stubbing.
