Molex Micro-Fit+ 215922, plug housing, 20 circuits, 2 rows, 0.118" (3.00mm) pitch, free-hanging, locking ramp, crimp termination, Black, PA66, -40°C to 105°C.
| Parameter | Value |
|---|---|
| Series | Micro-Fit+ 215922 |
| Type | Female Socket |
| Mounting | Free Hanging (In-Line) |
| Connector type | Plug |
| Fastening type | Locking Ramp |
| Operating temperature | -40°C ~ 105°C |
| Color | Black |
| Insulation material | Polyamide (PA66), Nylon 6/6 |
| Pitch | 0.118\" (3.00mm) |
| Package | Bulk |
| Rows | 2 |
| Contact termination | Crimp |
| Positions | 20 |
It carries 20 female socket positions in a dual-row arrangement on the standard 0.118" (3.00mm) pitch that defines the Micro-Fit family.
It mates with the corresponding Micro-Fit 3.0 male header or receptacle housing of the same 20-circuit, dual-row, 3.00mm pitch layout. The free-hanging (in-line) mounting style suits harness runs where a PCB mount is not available.
