Molex Micro-Fit+ 216571 series, 2165711006, single-row 6-position through-hole header, 3.00 mm pitch, shrouded 4-wall, locking ramp, tin-plated male pins, UL94 V-0 LCP housing, glow wire compliant.
| Parameter | Value |
|---|---|
| Series | Micro-Fit+ 216571 |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 600VAC/DC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.390\" (9.91mm) |
| Insulation material | Liquid Crystal Polymer (LCP), Glass Filled |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
| Features | Board Guide, Glow Wire Compliant |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.118\" (3.00mm) |
| Positions | 6 |
| Contact finish - post | Tin |
| Contact length - post | 0.125\" (3.18mm) |
| Contact finish - mating | Tin |
The 2165711006: 3.00 mm pitch sets the board footprint and the per-contact current ceiling. In a single-row 6-position layout, the 0.118" spacing leaves room for trace routing between pads on a standard 1 oz copper board.
This is a field-proven retention mechanism for wire-to-board interconnects in industrial and automotive environments.
The locking ramp on the header engages the latch on the receptacle.
Yes, the header is listed with the feature 'Glow Wire Compliant' — it meets the glow-wire ignition test for appliance and lighting equipment safety standards.
