2.00mm pitch SMT header for wire-to-board harnesses
The Molex 2170630025 is a 2.00mm pitch, 2-position male pin header designed for board-to-cable/wire interconnects.
Shrouded, latched, SMT — fit check for the board
The 2.00mm pitch sets the PCB footprint: each row of 2 positions on 0.079-inch centres. The 9.91mm insulation height (0.390-inch) gives clearance for the mating receptacle housing. Shrouded 4-wall design means the header accepts only the correctly keyed mating plug — no bent pins from a reversed or offset mate. The latch lock engages audibly on full insertion, a tactile check for the assembly line. Tin-Bismuth is a standard low-cost finish for moderate-cycle applications; it mates with the matching Tin-Bismuth or Tin-plated receptacle terminal. The brass base metal carries the current, derated per the wire gauge used.
