Molex 2182160410 Micro-Fit+ Header, 4 Pos, 3.00mm, SMT RA

MPN2182160410
Active

Molex Micro-Fit+ 218216 series, 2182160410, Board to Cable/Wire header, 4 circuits, 2 rows, 3.00mm pitch, Surface Mount, Right Angle, Tin mating finish, 12.5A per contact, 600VAC/DC, locking ramp, board lock, UL94 V-0.

$7.4900Ref. price · indicative, final on quote
Molex 2182160410 datasheet (PDF)
RoHSROHS3 Compliant
SeriesMicro-Fit+ 218216
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

2182160410 key specifications
ParameterValue
SeriesMicro-Fit+ 218216
TypeMale Pin
MountingSurface Mount, Right Angle
Connector typeHeader
Fastening typeLocking Ramp
Voltage rating600VAC/DC
Current rating12.5A per Contact
Operating temperature-40°C ~ 105°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation materialLiquid Crystal Polymer (LCP), Glass Filled
Material flammability ratingUL94 V-0

All specifications

2182160410 additional specifications
ParameterValue
StyleBoard to Cable/Wire
PackageTape & Reel (TR) Cut Tape (CT)
FeaturesBoard Lock, Retention Clips
ShroudingShrouded - 4 Wall
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.118\" (3.00mm)
Positions4
Row spacing - mating0.118\" (3.00mm)
Contact finish - postTin
Contact finish - matingTin

Product details

4-position, 3.00mm pitch SMT right-angle header

The 2182160410 is a 4-circuit, 2-row header from Molex Micro-Fit+ 218216 series, pitched at 3.00mm — the spacing that sets the board footprint and the per-contact current ceiling.

Tin plating and 12.5A current rating

The 12.5A per contact rating is derated from the full series maximum; the 4-position count keeps the total assembly current at 50A if all circuits are loaded. UL94 V-0 LCP housing and 600VAC/DC voltage rating suit the header for power distribution inside industrial or commercial equipment enclosures where flame retardance and isolation are required.

Mating half and build-to-print BOM

This header mates with a Micro-Fit+ receptacle housing (sold separately). The build-to-print BOM also requires the matching crimp terminals — Molex Micro-Fit+ terminal part numbers are listed in the series catalog. The 4-circuit, 2-row layout uses the standard 3.00mm pitch receptacle.

Frequently asked questions

What is the mating connector for 2182160410?

The mating half is a Micro-Fit+ receptacle housing (sold separately) with 4 circuits in 2 rows at 3.00mm pitch. You will also need the matching crimp terminals from the Micro-Fit+ series to complete the wire-to-board assembly.
