Molex 387600318

Molex Beau 38760 387600318, 18-Circuit Barrier Strip, 0.375" Pitch

MPN387600318
Active

Molex Beau 38760 387600318, 18-circuit dual-row barrier terminal strip, 0.375" (9.53 mm) pitch, 15 A, 300 V, flange-mount chassis/panel, top screws with captive plate, 14-22 AWG, black, UL94 V-0.

$11.47Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesBeau 38760
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026

Specifications

387600318 key specifications
ParameterValue
SeriesBeau 38760
Barrier type2 Wall (Dual)
MountingChassis, Panel
Terminal block typeBarrier Block
Voltage rating300V
Current rating15A
Wire gauge14-22 AWG
Terminal screw finishZinc, Chromate
Number of wire entries36
Terminal screw materialSteel
Operating temperature-40°C ~ 110°C
ColorBlack

All specifications

387600318 additional specifications
ParameterValue
Material - insulationThermoplastic
Material flammability ratingUL94 V-0
Pitch0.375\" (9.53mm)
PackageTray
FeaturesFlange
Rows2
Top terminationScrews with Captive Plate
Bottom terminationClosed
Number of circuits18

Product details

The 387600318: The 0.375" (9.53 mm) pitch sets the screw-terminal centers — wide enough for 14 AWG ring terminals without crowding, but the footprint on the panel or chassis needs an opening that matches the 18-circuit length. The UL94 V-0 rating means the housing will not sustain a flame after ignition — required for equipment inside a plenum or enclosure.

The 387600318 (18 circuits) shares the same 0.375" pitch, 15 A, 300 V, flange-mount, and dual-row layout as the 387600310 (10 circuits). If the BOM calls for 18 terminations in a single block, the 387600318 is the match; the 10-circuit 387600310 will not fit the same panel cutout or provide enough positions.

Frequently asked questions

What is the pitch of the 387600318?

The 387600318 has a 0.375" (9.53 mm) pitch between screw terminals.

What is the current and voltage rating of the 387600318?

It is rated 15 A per circuit at 300 V.

Where can I buy the 387600318 and get a price?

The 387600318 is sourced and quoted to order against an RFQ through independent distribution. Availability and current pricing are confirmed at the time of quote.
