Molex Beau 38780 barrier block, 387800109, 9 circuits, 0.438" (11.12 mm) pitch, 15 A, 300 V, dual-wall, screw-top, chassis/panel mount with flange, black, UL94 V-0, bulk.
| Parameter | Value |
|---|---|
| Series | Beau 38780 |
| Barrier type | 2 Wall (Dual) |
| Mounting | Chassis, Panel |
| Terminal block type | Barrier Block |
| Voltage rating | 300V |
| Current rating | 15A |
| Wire gauge | 14-22 AWG |
| Terminal screw finish | Zinc, Clear Chromate |
| Number of wire entries | 18 |
| Terminal screw material | Steel |
| Color | Black |
| Material - insulation | Thermoplastic |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Pitch | 0.438\" (11.12mm) |
| Package | Bulk |
| Features | Flange |
| Rows | 2 |
| Top termination | Screws |
| Bottom termination | Closed |
| Number of circuits | 9 |
The Molex Beau 38780 387800109 is a 9-circuit barrier strip terminal block with a 0.438" (11.12 mm) pitch, designed for chassis or panel mounting. The dual-wall barrier construction isolates each circuit, and the screw-top termination accepts 14-22 AWG wire.
The pitch is 0.438" (11.12 mm) between circuit centers.
No — the 387800109 is a 9-circuit block, while the 387800105 is 5 circuits. The per-position pitch and mounting flange are the same, but the overall length differs by four positions.
RoHS3 compliant and UL94 V-0 rated for flammability.
