Molex 397000703
MPN397000703
Active
TERM BLOCK 3POS 45DEG 3.5MM PCB
$1.67Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesEurostyle 39700
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Eurostyle 39700 |
| Mounting | Through Hole |
| Voltage | 300 V |
| Current | 5 A |
| Wire gauge | 16-20 AWG |
| Wire termination | Screwless - Push Button Clamp |
| Operating temperature | -40°C ~ 105°C |
| Color | Gray |
| Housing material | Polyamide (PA66), Nylon 6/6 |
| Contact material - plating | Phosphor Bronze - Tin Plated |
| Pitch | 0.138\" (3.50mm) |
| Package | Bulk |
| Number of levels | 1 |
| Mating orientation | 45° (135°) Angle with Board |
| Positions per level | 3 |
