Molex 43045-2016, Micro-Fit 3.0 vertical SMT header, dual-row, 15 circuits, ROHS3 compliant, Box package.
| Parameter | Value |
|---|---|
| Series | * |
| Package | Box |
The 43045-2016 is a Molex Micro-Fit 3.0 vertical SMT header, dual-row, with 15 circuits. The vertical orientation places the header pins perpendicular to the PCB, suiting board-edge or through-board mating with a Micro-Fit 3.0 receptacle. The SMT termination reflows with the board in a single pass — no secondary soldering step.
Sourced per RFQ.
The 43045-2016 is an active Molex part. Submit an RFQ for a firm quote.
The 43045-2016 is part of the Micro-Fit 3.0 series, which uses a 3.00 mm pitch.
Yes, the 43045-2016 is ROHS3 compliant.
The 43045-2016 is a Micro-Fit 3.0 header. The series uses a positive locking latch on the receptacle side — the header itself provides the latch retention feature when mated with the corresponding Micro-Fit 3.0 receptacle housing.
Yes, the 43045-2016 is a Micro-Fit 3.0 header and mates with Micro-Fit 3.0 receptacle housings that accept the corresponding crimp terminals.
