Molex 430452027

Molex Micro-Fit 3.0 430452027, 20-Pos 3mm Header, 8A

MPN430452027
Active

Molex Micro-Fit 3.0 43045 header, 430452027, 20 circuits, dual-row 3.00 mm pitch, 8 A per circuit at 600 V, tin-plated (1.52 µm), shrouded 4-wall, locking ramp, through-hole solder, UL94 V-0 LCP housing, -40°C to 105°C.

$5.55Ref. price · indicative, final on quote
Molex 430452027 datasheet (PDF)
RoHSROHS3 Compliant
SeriesMicro-Fit 3.0 43045
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026

Specifications

430452027 key specifications
ParameterValue
SeriesMicro-Fit 3.0 43045
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typeLocking Ramp
Voltage rating600V
Current rating8A
Operating temperature-40°C ~ 105°C
Contact materialBrass
Insulation colorBlack
Insulation height0.390\" (9.91mm)
Insulation materialLiquid Crystal Polymer (LCP), Glass Filled

All specifications

430452027 additional specifications
ParameterValue
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageTray
FeaturesBoard Guide
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsAutomotive, General Purpose, Industrial, Medical, Telecommunications
Contact shapeSquare
Rows2
Pitch0.118\" (3.00mm)
Positions20
Row spacing - mating0.118\" (3.00mm)
Contact finish - postTin
Contact length - post0.125\" (3.18mm)
Contact finish - matingTin
Contact finish thickness - mating60.0µin (1.52µm)

Product details

20-Pin Dual-Row Power Header for Wire-to-Board Harnesses

The Molex 430452027 is a 20-circuit, dual-row header from the Micro-Fit 3.0 43045 series. The 3.00 mm pitch and 0.125" (3.18 mm) solder-tail length suit standard through-hole PCB layouts. The housing is black UL94 V-0 LCP, rated from -40°C to 105°C, and the contacts are tin-plated (60.0 µin / 1.52 µm on the mating surface).

Locking Ramp and Full Shroud for Vibration Resistance

A built-in board guide aids alignment during automated assembly.

This header is specified for automotive, general-purpose industrial, medical, and telecommunications equipment. The UL94 V-0 rating satisfies flame-retardant requirements for equipment inside enclosures.

Frequently asked questions

What is the mating receptacle for molex 430452027?

The 430452027 mates with a Micro-Fit 3.0 receptacle housing of the same circuit count and pitch. Use the matching 20-circuit, 3.00 mm pitch receptacle from the same series.

Is molex 430452027 RoHS compliant?

Yes, the 430452027 is RoHS3 compliant per the manufacturer's listing.

What is the current rating and voltage of 430452027?

The header is rated 8 A per circuit at 600 V. Derate current above 105°C per the product's derating curve.

Does 430452027 have a locking feature?

Yes, the header has a locking ramp that engages with the receptacle latch for positive retention under vibration.
