Molex 464379302

Molex EXTreme Ten60Power 464379302, 2-Pos Right-Angle Plug

MPN464379302
Active

Molex EXTreme Ten60Power 46437 series 464379302, right-angle male-blade plug, 2 positions, 1 row, 5.50mm pitch, 60A per circuit, gold 30.0µin contacts, press-fit through-hole termination, 600VAC/250VDC, -40°C to 105°C, UL94 V-0, black, bulk.

$10.99Ref. price · indicative, final on quote
Molex 464379302 datasheet (PDF)
RoHSROHS3 Compliant
SeriesEXTreme Ten60Power 46437
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026

Specifications

464379302 specifications
ParameterValue
SeriesEXTreme Ten60Power 46437
MountingThrough Hole, Right Angle
Connector typeEXTreme Ten60Power
Voltage rating600VAC, 250VDC
Current rating60A
Operating temperature-40°C ~ 105°C
ColorBlack
Material flammability ratingUL94 V-0
Pitch0.217\" (5.50mm)
PackageBulk
FeaturesBoard Guide, Guide Pin
TerminationPress-Fit
Contact finishGold
Rows1
Positions2
Contact layout, typical2 Power
Contact finish thickness30.0µin (0.76µm)

Product details

Power-blade plug for bus-level distribution

The Molex 464379302 is a 2-position, right-angle male-blade plug from the EXTreme Ten60Power 46437 series.

Press-fit and right-angle — built for board-edge power entry

The press-fit termination presses into plated through-holes without solder, avoiding thermal shock to the PCB and allowing individual contact replacement if a blade is damaged. Board guides and a guide pin (listed features) align the plug during mating, protecting the blades from shear loads.

Frequently asked questions

What is the current rating of the 464379302?

The 464379302 is rated 60 A per circuit.

What is the pitch of the 464379302?

The pitch is 0.217" (5.50 mm).

What connector mates with the 464379302?

The 464379302 mates with the EXTreme Ten60Power receptacle housing (same series) — confirm the position count matches before ordering.
