Molex CLIK-Mate 503395 series, 3-position single-row receptacle, 1.50 mm pitch, tin-plated forked contacts, SMT termination with solder retention, beige PA46 housing rated UL94 V-0, -40°C to 105°C.
| Parameter | Value |
|---|---|
| Series | CLIK-Mate 503395 |
| Type | Forked |
| Mounting | Surface Mount |
| Connector type | Receptacle |
| Fastening type | Latch Holder |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Beige |
| Insulation height | 0.350\" (8.89mm) |
| Insulation material | Polyamide (PA46), Nylon 4/6 |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Parameter | Value |
|---|---|
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Solder Retention |
| Termination | Solder |
| Applications | Automotive, General Purpose, Industrial, Lighting, Medical |
| Rows | 1 |
| Pitch | 0.059\" (1.50mm) |
| Positions | 3 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 39.4µin (1.00µm) |
| Contact finish thickness - mating | 39.4µin (1.00µm) |
The 5033950310: The 1.50 mm pitch (0.059") sets the PCB footprint and the per-contact current ceiling — tin-plated contacts at this pitch typically carry 2-3 A, limited by the temperature rise in the PA46 housing.
For higher reconnect duty, the gold-plated variants in the CLIK-Mate series (e.g., 503395-0311) extend cycle life to 500+ mates.
The mating pitch is 0.059" (1.50 mm). This sets the PCB footprint and the minimum spacing between adjacent traces.
Yes, the part includes solder retention features — additional SMT pads that anchor the connector to the board during reflow and improve joint reliability under cable strain.
Yes, it is ROHS3 compliant.
