505278-1133 — Molex product photo
Molex

Molex 505278-1133 – 0.5mm Pitch 11-Conductor FFC ZIF Bottom

MPN505278-1133
Active

Molex 505278-1133, 0.5 mm pitch, 11-conductor FFC cable assembly with ZIF bottom contact termination, packaged in a Box. ROHS3 compliant, active production.

$0.3000Ref. price · indicative, final on quote
505278-1133 datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

505278-1133 Technical Specifications
ParameterValue
Series*
PackageBox

Product details

Pitch, Conductors, and ZIF Bottom Contact

The 505278-1133: This Molex FFC cable assembly uses a 0.5 mm pitch and carries 11 conductors – the pitch sets the mating footprint on the board, and the conductor count matches the corresponding ZIF connector's positions. The ZIF bottom contact design means the cable inserts into the connector with the contact pads facing down, common in space-constrained layouts where the cable routes flat against the board.

ROHS3 compliant; packaged in a Box.

Frequently asked questions

What is the pitch and number of conductors for Molex 505278-1133?

0.5 mm pitch, 11 conductors.

Is Molex 505278-1133 compatible with standard 0.5 mm ZIF FFC connectors?

Yes – the 0.5 mm pitch and 11 conductors match standard 0.5 mm ZIF connectors with 11 positions and bottom-contact orientation.
