0353170220
Molex
2Mini-Fit Jr 35317General Purpose, Industrial, Telecommunications
Ref. price$0.6600
Lead time on requestGet quote ›
Molex 0353 Series
23 variants · Molex
About the Molex 0353 Series
The Molex 0353 Series series groups 23 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common connector type of Header, contact material of Brass and contact shape of Square. Variants differ by applications, contact finish - mating and contact finish - post, so you can match the exact applications your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Molex 0353 Series variants and discontinued ones from a single page.
Select a variant by
- Applications
- Automotive, General Purpose · General Purpose, Industrial, Telecommunications
- Contact finish - mating
- Tin · Tin-Lead
- Contact finish - post
- - · Tin · Tin-Lead
- Contact finish thickness - mating
- - · 39.4µin (1.00µm) · 78.7µin (2.00µm)
- Contact finish thickness - post
- - · 39.4µin (1.00µm) · 78.7µin (2.00µm)
- Contact length - mating
- - · 0.145\" (3.70mm)
- Contact length - post
- 0.126\" (3.20mm) · 0.130\" (3.30mm) · 0.138\" (3.50mm)
- Insulation height
- 0.217\" (5.51mm) · 0.335\" (8.51mm) · 0.504\" (12.80mm)
Shared specifications
- Connector type
- Header
- Contact material
- Brass
- Contact shape
- Square
- Current rating
- -
- Fastening type
- Locking Ramp
- Features
- -
- Gender
- Male Pin
- Ingress protection
- -
- Insulation color
- Natural
- Package
- Bulk
- Shrouding
- Shrouded - 4 Wall
- Style
- Board to Cable/Wire
Variant comparison
| Parameter | 0353170220 | 0353620410 | 0353620510 | 0353620610 | 0353620710 | 0353620810 |
|---|---|---|---|---|---|---|
| Applications | General Purpose, Industrial, Telecommunications | Automotive, General Purpose | Automotive, General Purpose | Automotive, General Purpose | Automotive, General Purpose | Automotive, General Purpose |
| Contact finish - mating | Tin | Tin-Lead | Tin-Lead | Tin-Lead | Tin-Lead | Tin-Lead |
| Contact finish - post | Tin | Tin-Lead | Tin-Lead | Tin-Lead | Tin-Lead | Tin-Lead |
| Contact finish thickness - mating | - | 78.7µin (2.00µm) | 78.7µin (2.00µm) | 78.7µin (2.00µm) | 78.7µin (2.00µm) | 78.7µin (2.00µm) |
| Contact finish thickness - post | - | 78.7µin (2.00µm) | 78.7µin (2.00µm) | 78.7µin (2.00µm) | 78.7µin (2.00µm) | 78.7µin (2.00µm) |
| Contact length - mating | - | 0.145\" (3.70mm) | 0.145\" (3.70mm) | 0.145\" (3.70mm) | 0.145\" (3.70mm) | 0.145\" (3.70mm) |
| Contact length - post | 0.138\" (3.50mm) | 0.130\" (3.30mm) | 0.130\" (3.30mm) | 0.130\" (3.30mm) | 0.130\" (3.30mm) | 0.130\" (3.30mm) |
| Insulation height | 0.504\" (12.80mm) | 0.335\" (8.51mm) | 0.335\" (8.51mm) | 0.335\" (8.51mm) | 0.335\" (8.51mm) | 0.335\" (8.51mm) |
Request a quote on any Molex 0353 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Molex 0353 Series variants differ?
- Molex 0353 Series part numbers differ by applications, contact finish - mating, contact finish - post and contact finish thickness - mating. Use the selection guide above to pick by applications.
- How many Molex 0353 Series part numbers are listed?
- 23 Molex 0353 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Molex 0353 Series?
- Request a quote (RFQ) for any Molex 0353 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
