171-009-102L001
NorComp Inc.
9Grounding Indents2
Ref. price$1.03
Lead time on requestGet quote ›
NorComp Inc. 1710 Series
49 variants · NorComp Inc.
About the NorComp Inc. 1710 Series
The NorComp Inc. 1710 Series series groups 49 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common color of Black, contact finish of Gold and contact finish thickness of Flash. Variants differ by connector type, dielectric material and flange feature, so you can match the exact connector type your application requires using the selection guide below. All listed NorComp Inc. 1710 Series part numbers are active and orderable.
Select a variant by
- Connector type
- Plug, Male Pins · Receptacle, Female Sockets
- Dielectric material
- Polyamide (PA9T), Nylon 9T · Polybutylene Terephthalate (PBT) · Polybutylene Terephthalate (PBT), Glass Filled
- Flange feature
- Board Side (4-40) · Cable Side (4-40) · Housing/Shell (Unthreaded) · Mating Side (4-40)
- Mounting type
- Panel Mount · Panel Mount, Through Hole
- Shell material, finish
- Steel, Nickel Plated · Steel, Tin Plated
- Termination
- Solder · Solder Cup
- Contact material
- Brass · Copper Alloy
Shared specifications
- Color
- Black
- Contact finish
- Gold
- Contact finish thickness
- Flash
- Contact form
- Stamped
- Current rating
- 5A
- Gender
- Signal
- Material flammability rating
- UL94 V-0
- Operating temperature
- -50°C ~ 100°C
- Package
- Tray
- Positions
- 9
- Rows
- 2
- Shell size, connector layout
- 1 (DE, E)
Variant comparison
| Parameter | 171-009-102L001 | 171-009-103L001 | 171-009-103L011 | 171-009-103L021 | 171-009-113R001 | 171-009-113R011 |
|---|---|---|---|---|---|---|
| Connector type | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins |
| Dielectric material | Polybutylene Terephthalate (PBT), Glass Filled | Polybutylene Terephthalate (PBT), Glass Filled | Polybutylene Terephthalate (PBT), Glass Filled | Polybutylene Terephthalate (PBT), Glass Filled | Polyamide (PA9T), Nylon 9T | Polyamide (PA9T), Nylon 9T |
| Flange feature | Housing/Shell (Unthreaded) | Housing/Shell (Unthreaded) | Cable Side (4-40) | Cable Side (4-40) | Housing/Shell (Unthreaded) | Board Side (4-40) |
| Mounting type | Panel Mount | Panel Mount | Panel Mount | Panel Mount | Panel Mount, Through Hole | Panel Mount, Through Hole |
| Shell material, finish | Steel, Tin Plated | Steel, Nickel Plated | Steel, Nickel Plated | Steel, Nickel Plated | Steel, Nickel Plated | Steel, Nickel Plated |
| Termination | Solder Cup | Solder Cup | Solder Cup | Solder Cup | Solder | Solder |
| Contact material | Copper Alloy | Copper Alloy | Copper Alloy | Copper Alloy | Brass | Brass |
Request a quote on any NorComp Inc. 1710 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the NorComp Inc. 1710 Series variants differ?
- NorComp Inc. 1710 Series part numbers differ by connector type, dielectric material, flange feature and mounting type. Use the selection guide above to pick by connector type.
- How many NorComp Inc. 1710 Series part numbers are listed?
- 49 NorComp Inc. 1710 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for NorComp Inc. 1710 Series?
- Request a quote (RFQ) for any NorComp Inc. 1710 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
