173-E09-113R001
NorComp Inc.
9Grounding Indents-50°C ~ 100°C
Ref. price$4.9
Lead time on requestGet quote ›
NorComp Inc. 173E Series
11 variants · NorComp Inc.
About the NorComp Inc. 173E Series
The NorComp Inc. 173E Series series groups 11 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common backset spacing of 0.283\" (7.20mm), color of White and contact finish of Gold. Variants differ by connector type, contact material and flange feature, so you can match the exact connector type your application requires using the selection guide below. All listed NorComp Inc. 173E Series part numbers are active and orderable.
Select a variant by
- Connector type
- Plug, Male Pins · Receptacle, Female Sockets
- Contact material
- Brass · Copper
- Flange feature
- Housing/Shell (4-40) · Housing/Shell (Unthreaded) · Mating Side, Female Screwlock (4-40)
- Mounting type
- Panel Mount, Through Hole, Right Angle · Through Hole, Right Angle
- Operating temperature
- -55°C ~ 125°C · -50°C ~ 100°C
- Positions
- 9 · 15 · 25 · 37 · 50
- Rows
- 2 · 3
- Shell size, connector layout
- 1 (DE, E) · 2 (DA, A) · 3 (DB, B) · 4 (DC, C) · 5 (DD, D)
Shared specifications
- Backset spacing
- 0.283\" (7.20mm)
- Color
- White
- Contact finish
- Gold
- Contact finish thickness
- Flash
- Contact form
- Machined
- Current rating
- 5A
- Dielectric material
- Polyamide (PA6T), Nylon 6T
- Gender
- Signal
- Material flammability rating
- UL94 V-0
- Package
- Tray
- Shell material, finish
- Steel, Nickel Plated
- Termination
- Solder
Variant comparison
| Parameter | 173-E09-113R001 | 173-E09-113R141 | 173-E09-213R001 | 173-E15-113R141 | 173-E25-113R001 | 173-E25-213R001 |
|---|---|---|---|---|---|---|
| Connector type | Plug, Male Pins | Plug, Male Pins | Receptacle, Female Sockets | Plug, Male Pins | Plug, Male Pins | Receptacle, Female Sockets |
| Contact material | Brass | Brass | Copper | Brass | Brass | Copper |
| Flange feature | Housing/Shell (Unthreaded) | Mating Side, Female Screwlock (4-40) | Housing/Shell (Unthreaded) | Mating Side, Female Screwlock (4-40) | Housing/Shell (Unthreaded) | Housing/Shell (Unthreaded) |
| Mounting type | Panel Mount, Through Hole, Right Angle | Panel Mount, Through Hole, Right Angle | Through Hole, Right Angle | Panel Mount, Through Hole, Right Angle | Panel Mount, Through Hole, Right Angle | Through Hole, Right Angle |
| Operating temperature | -50°C ~ 100°C | -50°C ~ 100°C | -55°C ~ 125°C | -50°C ~ 100°C | -50°C ~ 100°C | -55°C ~ 125°C |
| Positions | 9 | 9 | 9 | 15 | 25 | 25 |
| Rows | 2 | 2 | 2 | 2 | 2 | 2 |
| Shell size, connector layout | 1 (DE, E) | 1 (DE, E) | 1 (DE, E) | 2 (DA, A) | 3 (DB, B) | 3 (DB, B) |
Request a quote on any NorComp Inc. 173E Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the NorComp Inc. 173E Series variants differ?
- NorComp Inc. 173E Series part numbers differ by connector type, contact material, flange feature and mounting type. Use the selection guide above to pick by connector type.
- How many NorComp Inc. 173E Series part numbers are listed?
- 11 NorComp Inc. 173E Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for NorComp Inc. 173E Series?
- Request a quote (RFQ) for any NorComp Inc. 173E Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
