EDZ950/12
On Shore Technology Inc.
120.200\" (5.08mm)EDZ950
Ref. price$8.1200
Lead time on requestGet quote ›
On Shore Technology Inc. EDZ9 Series
10 variants · On Shore Technology Inc.
About the On Shore Technology Inc. EDZ9 Series
The On Shore Technology Inc. EDZ9 Series series groups 10 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common color of Green, contact mating finish of - and contact tail length of -. Variants differ by contact material, pitch and positions, so you can match the exact contact material your application requires using the selection guide below. All listed On Shore Technology Inc. EDZ9 Series part numbers are active and orderable.
Select a variant by
- Contact material
- Copper · Copper Tin Alloy
- Pitch
- 0.200\" (5.08mm) · 0.300\" (7.62mm)
- Positions
- 2 · 3 · 4 · 7 · 8 · 12 · 16
- Positions per level
- 2 · 3 · 4 · 7 · 8 · 12 · 16
- Wire gauge or range - AWG
- 12-22 AWG · 12-28 AWG
Shared specifications
- Color
- Green
- Contact mating finish
- -
- Contact tail length
- -
- Current - IEC
- -
- Features
- -
- Header orientation
- -
- Housing material
- Polyamide (PA), Nylon
- Ingress protection
- -
- Insulation height
- -
- Material flammability rating
- UL94 V-0
- Mounting type
- Free Hanging (In-Line)
- Number of levels
- 1
Variant comparison
| Parameter | EDZ950/12 | EDZ950/16 | EDZ950/2 | EDZ950/3 | EDZ950/4 | EDZ950/7 |
|---|---|---|---|---|---|---|
| Contact material | Copper | Copper | Copper | Copper | Copper | Copper |
| Pitch | 0.200\" (5.08mm) | 0.200\" (5.08mm) | 0.200\" (5.08mm) | 0.200\" (5.08mm) | 0.200\" (5.08mm) | 0.200\" (5.08mm) |
| Positions | 12 | 16 | 2 | 3 | 4 | 7 |
| Positions per level | 12 | 16 | 2 | 3 | 4 | 7 |
| Wire gauge or range - AWG | 12-22 AWG | 12-22 AWG | 12-22 AWG | 12-22 AWG | 12-22 AWG | 12-22 AWG |
Request a quote on any On Shore Technology Inc. EDZ9 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the On Shore Technology Inc. EDZ9 Series variants differ?
- On Shore Technology Inc. EDZ9 Series part numbers differ by contact material, pitch, positions and positions per level. Use the selection guide above to pick by contact material.
- How many On Shore Technology Inc. EDZ9 Series part numbers are listed?
- 10 On Shore Technology Inc. EDZ9 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for On Shore Technology Inc. EDZ9 Series?
- Request a quote (RFQ) for any On Shore Technology Inc. EDZ9 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
