Phoenix Contact 3249198
MPN3249198
Active
TERM BLK MIDDLE 4POS 10.4MM GRAY
$2.73Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesCLIPLINE ST
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Type | Middle |
| Series | CLIPLINE ST |
| Mounting | Direct Mount |
| Voltage - UL | 300 V |
| Voltage - IEC | 800 V |
| Current - UL | 20 A |
| Current - IEC | 24 A |
| Terminal - width | 10.4mm |
| Wire gauge or range - AWG | 12-28 AWG |
| Wire gauge or range - mm2 | 0.08-4mm² |
| Height | 0.866\" (22.00mm) |
| Housing color | Gray |
All specifications
| Parameter | Value |
|---|---|
| Material - insulation | Polyamide (PA), Nylon |
| Material flammability rating | UL94 V-0 |
| Length | 1.260\" (32.00mm) |
| Package | Bulk |
| Number of levels | 1 |
| Stripping length | 8mm |
| Termination style | Push In, Spring |
| Positions | 4 |
