3209015
Phoenix Contact
GrayCLIPLINE STIOFeed Through, Isolated (2)
Ref. price$5.94
Lead time on requestGet quote ›
Phoenix Contact 3209 Series
20 variants · Phoenix Contact
About the Phoenix Contact 3209 Series
The Phoenix Contact 3209 Series series groups 20 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common material - insulation of Polyamide (PA), Nylon, material flammability rating of UL94 V-0 and terminal - width of 5.2mm. Variants differ by color, number of levels and package, so you can match the exact color your application requires using the selection guide below. All listed Phoenix Contact 3209 Series part numbers are active and orderable.
Select a variant by
- Color
- Blue · Gray · Green · Green, Yellow · Red · White
- Number of levels
- 1 · 2
- Package
- Box · Bulk
- Positions
- 2 · 3 · 4
- Stripping length
- 8mm · 10mm
- Type
- Feed Through · Feed Through, Isolated (2) · Ground, Earth
- Wire gauge or range - AWG
- 12-26 AWG · 12-28 AWG
Shared specifications
- Material - insulation
- Polyamide (PA), Nylon
- Material flammability rating
- UL94 V-0
- Terminal - width
- 5.2mm
- Termination style
- Push In, Spring
Variant comparison
| Parameter | 3209015 | 3209510 | 3209512 | 3209523 | 3209536 | 3209552 |
|---|---|---|---|---|---|---|
| Color | Gray | Gray | Red | Blue | Green, Yellow | Blue |
| Number of levels | 2 | 1 | 1 | 1 | 1 | 1 |
| Package | Bulk | Box | Bulk | Box | Box | Box |
| Positions | 4 | 2 | 2 | 2 | 2 | 3 |
| Stripping length | 10mm | 10mm | 10mm | 10mm | 10mm | 10mm |
| Type | Feed Through, Isolated (2) | Feed Through | Feed Through | Feed Through | Ground, Earth | Feed Through |
| Wire gauge or range - AWG | 12-28 AWG | 12-26 AWG | 12-26 AWG | 12-26 AWG | 12-26 AWG | 12-26 AWG |
Request a quote on any Phoenix Contact 3209 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Phoenix Contact 3209 Series variants differ?
- Phoenix Contact 3209 Series part numbers differ by color, number of levels, package and positions. Use the selection guide above to pick by color.
- How many Phoenix Contact 3209 Series part numbers are listed?
- 20 Phoenix Contact 3209 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Phoenix Contact 3209 Series?
- Request a quote (RFQ) for any Phoenix Contact 3209 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
