739W-X2/03
Qualtek
IDCTerminating CoverSquare - 24.50mm x 24.50mm
Ref. price$1.5400
Lead time on requestGet quote ›
Qualtek 739WX2 Series
10 variants · Qualtek
About the Qualtek 739WX2 Series
The Qualtek 739WX2 Series series groups 10 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common connector type of Receptacle, Female Sockets, ingress protection of - and material flammability rating of -. Variants differ by approval agency, current rating and features, so you can match the exact approval agency your application requires using the selection guide below. All listed Qualtek 739WX2 Series part numbers are active and orderable.
Select a variant by
- Approval agency
- CSA, cUL, UL · CSA, UL · cUL, UL
- Current rating
- 10A · 15A · 20A
- Features
- - · Tamper Resistant, Terminating Cover · Terminating Cover
- Panel cutout
- Rectangular - 31.50mm x 24.50mm · Square - 24.50mm x 24.50mm
- Panel thickness
- 0.031\" ~ 0.071\" (0.79mm ~ 1.80mm) · 0.031\" ~ 0.071\" (0.80mm ~ 1.80mm) · 0.031\" ~ 0.079\" (0.79mm ~ 2.00mm)
- Termination
- IDC · IDC, Quick Connect - 0.189\" (4.8mm) · Quick Connect - 0.189\" (4.8mm) · Solder
- Voltage rating
- 125VAC · 250VAC
Shared specifications
- Connector type
- Receptacle, Female Sockets
- Ingress protection
- -
- Material flammability rating
- -
- Mounting type
- Panel Mount, Snap-In
- Package
- Bulk
- Positions
- 3
Variant comparison
| Parameter | 739W-X2/03 | 739W-X2/04 | 739W-X2/20 | 739W-X2/20-WH1 | 739W-X2/30 | 739W-X2/32 |
|---|---|---|---|---|---|---|
| Approval agency | CSA, UL | CSA, cUL, UL | cUL, UL | cUL, UL | cUL, UL | cUL, UL |
| Current rating | 15A | 10A | 20A | 20A | 20A | 15A |
| Features | Terminating Cover | Terminating Cover | Terminating Cover | Terminating Cover | Terminating Cover | - |
| Panel cutout | Square - 24.50mm x 24.50mm | Square - 24.50mm x 24.50mm | Square - 24.50mm x 24.50mm | Square - 24.50mm x 24.50mm | Square - 24.50mm x 24.50mm | Square - 24.50mm x 24.50mm |
| Panel thickness | 0.031\" ~ 0.071\" (0.79mm ~ 1.80mm) | 0.031\" ~ 0.071\" (0.79mm ~ 1.80mm) | 0.031\" ~ 0.071\" (0.79mm ~ 1.80mm) | 0.031\" ~ 0.071\" (0.80mm ~ 1.80mm) | 0.031\" ~ 0.071\" (0.79mm ~ 1.80mm) | 0.031\" ~ 0.071\" (0.80mm ~ 1.80mm) |
| Termination | IDC | IDC, Quick Connect - 0.189\" (4.8mm) | IDC | IDC | Solder | Solder |
| Voltage rating | 125VAC | 125VAC | 125VAC | 125VAC | 125VAC | 125VAC |
Request a quote on any Qualtek 739WX2 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Qualtek 739WX2 Series variants differ?
- Qualtek 739WX2 Series part numbers differ by approval agency, current rating, features and panel cutout. Use the selection guide above to pick by approval agency.
- How many Qualtek 739WX2 Series part numbers are listed?
- 10 Qualtek 739WX2 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Qualtek 739WX2 Series?
- Request a quote (RFQ) for any Qualtek 739WX2 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
