ASP-103612-01
Samtec Inc.
11460.050\" (1.27mm)
Ref. price$29.58
Lead time on requestGet quote ›
Samtec Inc. ASP1 Series
34 variants · Samtec Inc.
About the Samtec Inc. ASP1 Series
The Samtec Inc. ASP1 Series series groups 34 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common contact finish of Gold and mounting type of Surface Mount. Variants differ by connector type, contact finish thickness and height above board, so you can match the exact connector type your application requires using the selection guide below. All listed Samtec Inc. ASP1 Series part numbers are active and orderable.
Select a variant by
- Connector type
- Array, Female Sockets · Array, Male Pins · Header, Outer Shroud Contacts
- Contact finish thickness
- 30.0µin (0.76µm) · Flash
- Height above board
- 0.104\" (2.65mm) · 0.118\" (3.00mm) · 0.130\" (3.30mm) · 0.134\" (3.40mm) · 0.168\" (4.27mm) · 0.280\" (7.10mm) · 0.327\" (8.30mm) · 0.342\" (8.68mm) · 0.363\" (9.22mm)
- Package
- Strip · Tape & Reel (TR); Cut Tape (CT) · Tray
- Pitch
- 0.020\" (0.50mm) · 0.025\" (0.64mm) · 0.050\" (1.27mm)
- Positions
- 52 · 114 · 156 · 160
- Rows
- 2 · 4 · 6
- Features
- Board Guide · Board Guide, Ground Bus (Plane) · Pick and Place
Shared specifications
- Contact finish
- Gold
- Mounting type
- Surface Mount
Variant comparison
| Parameter | ASP-103612-01 | ASP-103612-02 | ASP-103612-04 | ASP-103612-05 | ASP-103614-01 | ASP-103614-04 |
|---|---|---|---|---|---|---|
| Connector type | Array, Female Sockets | Array, Female Sockets | Array, Female Sockets | Array, Female Sockets | Array, Male Pins | Array, Male Pins |
| Contact finish thickness | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) |
| Height above board | 0.130\" (3.30mm) | 0.130\" (3.30mm) | 0.134\" (3.40mm) | 0.104\" (2.65mm) | 0.363\" (9.22mm) | 0.363\" (9.22mm) |
| Package | Strip | Strip | Strip | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Strip |
| Pitch | 0.050\" (1.27mm) | 0.050\" (1.27mm) | 0.050\" (1.27mm) | 0.050\" (1.27mm) | 0.050\" (1.27mm) | 0.050\" (1.27mm) |
| Positions | 114 | 114 | 114 | 114 | 114 | 114 |
| Rows | 6 | 6 | 6 | 6 | 6 | 6 |
| Features | — | — | — | Pick and Place | — | — |
Request a quote on any Samtec Inc. ASP1 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Samtec Inc. ASP1 Series variants differ?
- Samtec Inc. ASP1 Series part numbers differ by connector type, contact finish thickness, height above board and package. Use the selection guide above to pick by connector type.
- How many Samtec Inc. ASP1 Series part numbers are listed?
- 34 Samtec Inc. ASP1 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Samtec Inc. ASP1 Series?
- Request a quote (RFQ) for any Samtec Inc. ASP1 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
