TCSD-20-01-N
Samtec Inc.
Feed Through, Polarizing KeyBlackTube
Ref. price$7.68
Lead time on requestGet quote ›
Samtec Inc. TCSD Series
20 variants · Samtec Inc.
About the Samtec Inc. TCSD Series
The Samtec Inc. TCSD Series series groups 20 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common cable termination of IDC, contact finish of Gold and rows of 2. Variants differ by color, connector type and contact finish thickness, so you can match the exact color your application requires using the selection guide below. All listed Samtec Inc. TCSD Series part numbers are active and orderable.
Select a variant by
- Color
- Black · Gray, Ribbon
- Connector type
- Receptacle · Socket to Socket · Socket to Socket, Reversed
- Contact finish thickness
- 30.0µin (0.76µm) · Flash
- Package
- Bulk · Tube
- Positions
- 40 · 50
- Length
- 0.167' (50.80mm, 2.00\") · 0.208' (63.50mm, 2.50\") · 0.458' (139.70mm, 5.50\") · 0.567' (172.72mm, 6.80\") · 0.583' (177.80mm, 7.00\") · 0.937' (285.75mm, 11.25\") · 1.00' (304.80mm) · 1.17' (355.62mm) · 1.75' (533.40mm)
- Features
- Feed Through, Polarizing Key · Polarizing Key · Polarizing Key, Strain Relief
Shared specifications
- Cable termination
- IDC
- Contact finish
- Gold
- Rows
- 2
Variant comparison
| Parameter | TCSD-20-01-N | TCSD-20-D-02.00-01-N-SR | TCSD-20-D-02.50-01-R | TCSD-20-D-05.50-01-N | TCSD-20-D-06.80-01-N-R | TCSD-20-D-07.00-01-N-R |
|---|---|---|---|---|---|---|
| Color | Black | Gray, Ribbon | Gray, Ribbon | Gray, Ribbon | Gray, Ribbon | Gray, Ribbon |
| Connector type | Receptacle | Socket to Socket | Socket to Socket, Reversed | Socket to Socket | Socket to Socket, Reversed | Socket to Socket, Reversed |
| Contact finish thickness | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) |
| Package | Tube | Bulk | Bulk | Bulk | Bulk | Bulk |
| Positions | 40 | 40 | 40 | 40 | 40 | 40 |
| Length | — | 0.167' (50.80mm, 2.00\") | 0.208' (63.50mm, 2.50\") | 0.458' (139.70mm, 5.50\") | 0.567' (172.72mm, 6.80\") | 0.583' (177.80mm, 7.00\") |
| Features | Feed Through, Polarizing Key | Polarizing Key, Strain Relief | — | Polarizing Key | Polarizing Key | Polarizing Key |
Request a quote on any Samtec Inc. TCSD Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Samtec Inc. TCSD Series variants differ?
- Samtec Inc. TCSD Series part numbers differ by color, connector type, contact finish thickness and package. Use the selection guide above to pick by color.
- How many Samtec Inc. TCSD Series part numbers are listed?
- 20 Samtec Inc. TCSD Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Samtec Inc. TCSD Series?
- Request a quote (RFQ) for any Samtec Inc. TCSD Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
