1658606-1
TE Connectivity AMP Connectors
50Feed ThroughAMPLIMITE HDF-20
Ref. price$30.86
Lead time on requestGet quote ›
TE Connectivity AMP Connectors 16586 Series
32 variants · TE Connectivity AMP Connectors
About the TE Connectivity AMP Connectors 16586 Series
The TE Connectivity AMP Connectors 16586 Series series groups 32 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common color of Black, contact finish of Gold and contact material of Phosphor Bronze. Variants differ by connector type, features and flange feature, so you can match the exact connector type your application requires using the selection guide below. All listed TE Connectivity AMP Connectors 16586 Series part numbers are active and orderable.
Select a variant by
- Connector type
- Plug, Male Pins · Receptacle, Female Sockets
- Features
- Feed Through · Feed Through, Grounding Indents
- Flange feature
- Housing/Shell (4-40) · Housing/Shell (Unthreaded)
- Positions
- 9 · 15 · 25 · 37 · 50
- Rows
- 2 · 3
- Shell size, connector layout
- 1 (DE, E) · 2 (DA, A) · 3 (DB, B) · 4 (DC, C) · 5 (DD, D)
- Contact finish thickness
- 30.0µin (0.76µm) · Flash
Shared specifications
- Color
- Black
- Contact finish
- Gold
- Contact material
- Phosphor Bronze
- Current rating
- 1.25A
- Dielectric material
- Thermoplastic
- Gender
- Signal
- Material flammability rating
- UL94 V-0
- Mounting type
- Free Hanging (In-Line)
- Operating temperature
- -55°C ~ 105°C
- Package
- Bulk
- Termination
- IDC, Ribbon Cable
Variant comparison
| Parameter | 1658606-1 | 1658607-1 | 1658608-1 | 1658608-2 | 1658609-1 | 1658609-4 |
|---|---|---|---|---|---|---|
| Connector type | Receptacle, Female Sockets | Plug, Male Pins | Plug, Male Pins | Plug, Male Pins | Receptacle, Female Sockets | Receptacle, Female Sockets |
| Features | Feed Through | Feed Through, Grounding Indents | Feed Through, Grounding Indents | Feed Through, Grounding Indents | Feed Through | Feed Through |
| Flange feature | Housing/Shell (4-40) | Housing/Shell (4-40) | Housing/Shell (4-40) | Housing/Shell (4-40) | Housing/Shell (4-40) | Housing/Shell (4-40) |
| Positions | 50 | 50 | 37 | 25 | 37 | 9 |
| Rows | 3 | 3 | 2 | 2 | 2 | 2 |
| Shell size, connector layout | 5 (DD, D) | 5 (DD, D) | 4 (DC, C) | 3 (DB, B) | 4 (DC, C) | 1 (DE, E) |
| Contact finish thickness | 30.0µin (0.76µm) | Flash | — | — | 30.0µin (0.76µm) | 30.0µin (0.76µm) |
Request a quote on any TE Connectivity AMP Connectors 16586 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
