1-776200-1
TE Connectivity AMP Connectors
23-40°C ~ 125°C0.157\" (4.00mm)
Ref. price$13.9500
Lead time on requestGet quote ›
TE Connectivity AMP Connectors 1776 Series
285 variants · TE Connectivity AMP Connectors
About the TE Connectivity AMP Connectors 1776 Series
The TE Connectivity AMP Connectors 1776 Series series groups 285 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common ingress protection of - and package of Bulk. Variants differ by contact material, features and insulation height, so you can match the exact contact material your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current TE Connectivity AMP Connectors 1776 Series variants and discontinued ones from a single page.
Select a variant by
- Contact material
- Brass · Copper Alloy · Phosphor Bronze
- Features
- - · Interlocking (Side) · Mating Flange · Mounting Flange, Sealable · Mounting Flange, Sealed
- Insulation height
- - · 0.285\" (7.25mm) · 0.362\" (9.20mm) · 0.472\" (12.00mm) · 0.902\" (22.90mm)
- Material flammability rating
- - · UL94 V-0
- Mounting type
- Panel Mount, Through Hole · Through Hole
- Operating temperature
- -40°C ~ 110°C · -40°C ~ 125°C · -40°C~110°C
- Pitch
- 0.138\" (3.50mm) · 0.150\" (3.81mm) · 0.157\" (4.00mm) · 0.197\" (5.00mm) · 0.200\" (5.08mm)
- Positions
- 2 · 4 · 5 · 6 · 8 · 10 · 12 · 16 · 23
Shared specifications
- Ingress protection
- -
- Package
- Bulk
Variant comparison
| Parameter | 1776130-4 | 1776131-5 | 1776134-8 | 1776136-2 | 1776147-4 | 1776166-2 |
|---|---|---|---|---|---|---|
| Contact material | Phosphor Bronze | Phosphor Bronze | Brass | Phosphor Bronze | Copper Alloy | Copper Alloy |
| Features | - | - | - | Mating Flange | - | Interlocking (Side) |
| Insulation height | 0.362\" (9.20mm) | 0.362\" (9.20mm) | 0.285\" (7.25mm) | 0.285\" (7.25mm) | 0.472\" (12.00mm) | 0.902\" (22.90mm) |
| Material flammability rating | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 | UL94 V-0 |
| Mounting type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Operating temperature | -40°C ~ 110°C | -40°C~110°C | -40°C~110°C | -40°C~110°C | -40°C~110°C | -40°C ~ 110°C |
| Pitch | 0.138\" (3.50mm) | 0.150\" (3.81mm) | 0.138\" (3.50mm) | 0.138\" (3.50mm) | 0.200\" (5.08mm) | 0.197\" (5.00mm) |
| Positions | 4 | 5 | 8 | 2 | 4 | 4 |
Request a quote on any TE Connectivity AMP Connectors 1776 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the TE Connectivity AMP Connectors 1776 Series variants differ?
- TE Connectivity AMP Connectors 1776 Series part numbers differ by contact material, features, insulation height and material flammability rating. Use the selection guide above to pick by contact material.
- How many TE Connectivity AMP Connectors 1776 Series part numbers are listed?
- 285 TE Connectivity AMP Connectors 1776 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for TE Connectivity AMP Connectors 1776 Series?
- Request a quote (RFQ) for any TE Connectivity AMP Connectors 1776 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
