1-6609016-3
TE Connectivity Corcom Filters
Wire LeadsED, CorcomFront or Rear Side Mount
Ref. price$18.93
Lead time on requestGet quote ›
TE Connectivity Corcom Filters 1660 Series
4 variants · TE Connectivity Corcom Filters
About the TE Connectivity Corcom Filters 1660 Series
The TE Connectivity Corcom Filters 1660 Series series groups 4 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common approval agency of CSA, UL, VDE, filter type of Filtered (EMI, RFI) - Commercial and mounting type of Panel Mount, Flange. Variants differ by accomodates a fuse, connector type and current rating - appliance inlet, so you can match the exact accomodates a fuse your application requires using the selection guide below. All listed TE Connectivity Corcom Filters 1660 Series part numbers are active and orderable.
Select a variant by
- Accomodates a fuse
- No · Yes (Fuse Not Included)
- Connector type
- Receptacle, Male Blades · Receptacle, Male Blades - Module
- Current rating - appliance inlet
- 5A · 6A · 10A
- Current rating - filter
- 5A · 6A · 10A
- Panel cutout
- Rectangular - 83.06mm x 29.21mm · Variable Size
- Termination
- Quick Connect - 0.110\" (2.8mm) · Quick Connect - 0.187\" (4.7mm) · Quick Connect - 0.250\" (6.3mm) · Wire Leads
- Voltage rating - appliance inlet
- 120/250VAC · 120VAC
Shared specifications
- Approval agency
- CSA, UL, VDE
- Filter type
- Filtered (EMI, RFI) - Commercial
- Mounting type
- Panel Mount, Flange
- Package
- Bulk
- Positions
- 3
Variant comparison
| Parameter | 1-6609016-3 | 1-6609016-6 | 1-6609130-3 | 1-6609929-5 |
|---|---|---|---|---|
| Accomodates a fuse | No | No | Yes (Fuse Not Included) | Yes (Fuse Not Included) |
| Connector type | Receptacle, Male Blades | Receptacle, Male Blades | Receptacle, Male Blades - Module | Receptacle, Male Blades - Module |
| Current rating - appliance inlet | 6A | 10A | 5A | 10A |
| Current rating - filter | 6A | 10A | 5A | 10A |
| Panel cutout | Variable Size | Variable Size | Rectangular - 83.06mm x 29.21mm | Variable Size |
| Termination | Wire Leads | Quick Connect - 0.250\" (6.3mm) | Quick Connect - 0.110\" (2.8mm) | Quick Connect - 0.187\" (4.7mm) |
| Voltage rating - appliance inlet | 120/250VAC | 120/250VAC | 120VAC | 120VAC |
Request a quote on any TE Connectivity Corcom Filters 1660 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the TE Connectivity Corcom Filters 1660 Series variants differ?
- TE Connectivity Corcom Filters 1660 Series part numbers differ by accomodates a fuse, connector type, current rating - appliance inlet and current rating - filter. Use the selection guide above to pick by accomodates a fuse.
- How many TE Connectivity Corcom Filters 1660 Series part numbers are listed?
- 4 TE Connectivity Corcom Filters 1660 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for TE Connectivity Corcom Filters 1660 Series?
- Request a quote (RFQ) for any TE Connectivity Corcom Filters 1660 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
