8-6609107-1
TE Connectivity Corcom Filters
ShieldedVariable SizeP, Corcom
Ref. price$35.1500
Lead time on requestGet quote ›
TE Connectivity Corcom Filters 8660 Series
4 variants · TE Connectivity Corcom Filters
About the TE Connectivity Corcom Filters 8660 Series
The TE Connectivity Corcom Filters 8660 Series series groups 4 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common accomodates a fuse of Yes (Fuse Not Included), approval agency of CSA, UL, VDE and connector type of Receptacle, Male Blades - Module. Variants differ by current rating - appliance inlet, current rating - filter and features, so you can match the exact current rating - appliance inlet your application requires using the selection guide below. All listed TE Connectivity Corcom Filters 8660 Series part numbers are active and orderable.
Select a variant by
- Current rating - appliance inlet
- 6A · 10A
- Current rating - filter
- 6A · 10A
- Features
- Conversion Clip · Conversion Clip, Shielded, Voltage Selector · Shielded · Shielded, Voltage Selector
- Fuse holder, drawer
- Fuse Holder · Fuse Holder, Twin Fused
- Mounting type
- Panel Mount, Flange · Panel Mount, Snap-In
- Panel cutout
- Rectangular - 26.92mm x 66.04mm · Rectangular - 28.45mm x 55.91mm · Variable Size
- Panel thickness
- 0.031\" ~ 0.114\" (0.79mm ~ 2.90mm) · 0.225\" (5.72mm)
Shared specifications
- Accomodates a fuse
- Yes (Fuse Not Included)
- Approval agency
- CSA, UL, VDE
- Connector type
- Receptacle, Male Blades - Module
- Current rating - circuit breaker
- -
- Filter type
- Filtered (EMI, RFI) - Commercial
- Ingress protection
- -
- Material flammability rating
- -
- Package
- Bulk
- Positions
- 3
- Switch features
- Switch On-Off
- Termination
- Quick Connect - 0.187\" (4.7mm)
- Voltage rating - appliance inlet
- 120VAC
Variant comparison
| Parameter | 8-6609107-1 | 8-6609107-7 | 8-6609107-9 | 8-6609928-6 |
|---|---|---|---|---|
| Current rating - appliance inlet | 10A | 6A | 10A | 10A |
| Current rating - filter | 10A | 6A | 10A | 10A |
| Features | Shielded | Conversion Clip | Shielded, Voltage Selector | Conversion Clip, Shielded, Voltage Selector |
| Fuse holder, drawer | Fuse Holder, Twin Fused | Fuse Holder | Fuse Holder, Twin Fused | Fuse Holder |
| Mounting type | Panel Mount, Snap-In | Panel Mount, Snap-In | Panel Mount, Snap-In | Panel Mount, Flange |
| Panel cutout | Variable Size | Rectangular - 26.92mm x 66.04mm | Rectangular - 28.45mm x 55.91mm | Variable Size |
| Panel thickness | 0.031\" ~ 0.114\" (0.79mm ~ 2.90mm) | 0.225\" (5.72mm) | 0.225\" (5.72mm) | 0.031\" ~ 0.114\" (0.79mm ~ 2.90mm) |
Request a quote on any TE Connectivity Corcom Filters 8660 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the TE Connectivity Corcom Filters 8660 Series variants differ?
- TE Connectivity Corcom Filters 8660 Series part numbers differ by current rating - appliance inlet, current rating - filter, features and fuse holder, drawer. Use the selection guide above to pick by current rating - appliance inlet.
- How many TE Connectivity Corcom Filters 8660 Series part numbers are listed?
- 4 TE Connectivity Corcom Filters 8660 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for TE Connectivity Corcom Filters 8660 Series?
- Request a quote (RFQ) for any TE Connectivity Corcom Filters 8660 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
