WAGO Corporation 2086 Series

34 variants · WAGO Corporation

WAGO Corporation 2086 Series — wago-corporation

WAGO Corporation 2086 Series offers 34 variants for board-to-board, wire-to-board, and cable assembly applications.

Applications

PCB assembly, wire harness manufacturing, field service connectors.

Selection

Pitch (2.54mm to 0.50mm), positions/rows, termination (SMT, through-hole, crimp), contact plating (gold flash to 30u Au), and housing (UL 94V-0).

Availability

Standard configurations broadly stocked in distributor inventory.

About the WAGO Corporation 2086 Series

The WAGO Corporation 2086 Series series groups 34 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common clamp material - plating of Steel - Nickel Plated, color of Black and contact material - plating of Electrolytic Copper - Tin Plated. Variants differ by mating orientation, mounting type and package, so you can match the exact mating orientation your application requires using the selection guide below. All listed WAGO Corporation 2086 Series part numbers are active and orderable.

Select a variant by

Mating orientation: Horizontal with Board · Vertical with Board
Mounting type: Surface Mount · Through Hole
Package: Tape & Reel (TR); Cut Tape (CT) · Tray
Positions per level: 2 · 4 · 5 · 6 · 7 · 8 · 10 · 11

Shared specifications

Clamp material - plating: Steel - Nickel Plated
Color: Black
Contact material - plating: Electrolytic Copper - Tin Plated
Current: 10 A
Features: Push Button Actuated
Housing material: Polyphthalamide (PPA), Glass Filled
Number of levels: 1
Operating temperature: -60°C ~ 105°C
Pitch: 0.138\" (3.50mm)
Voltage: 300 V
Wire gauge: 16-24 AWG
Wire termination: Screwless - Push Button Clamp

Variant comparison

Parameter	2086-1110	2086-1110/700-000/997-607	2086-1111/700-000/997-607	2086-1122	2086-1124	2086-1125
Mating orientation	Vertical with Board	Vertical with Board	Vertical with Board	Vertical with Board	Vertical with Board	Vertical with Board
Mounting type	Through Hole	Surface Mount	Surface Mount	Through Hole	Through Hole	Through Hole
Package	Tray	Tape & Reel (TR); Cut Tape (CT)	Tape & Reel (TR); Cut Tape (CT)	Tray	Tray	Tray
Positions per level	10	10	11	2	4	5

Request a quote on any WAGO Corporation 2086 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
