231-302/037-000
WAGO Corporation
2Lever Actuated, Retention Latches (Non-Wire Side)16A
Ref. price$4.3900
Lead time on requestGet quote ›
WAGO Corporation 2313 Series
10 variants · WAGO Corporation
About the WAGO Corporation 2313 Series
The WAGO Corporation 2313 Series series groups 10 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common color of Orange, contact mating finish of Tin and housing material of Polyamide (PA66), Nylon 6/6. Variants differ by contact material, contact tail length and current - IEC, so you can match the exact contact material your application requires using the selection guide below. All listed WAGO Corporation 2313 Series part numbers are active and orderable.
Select a variant by
- Contact material
- Copper Alloy · Electrolytic Copper
- Contact tail length
- - · 0.197\" (5.00mm)
- Current - IEC
- 12A · 16A
- Current - UL
- 10 A · 15 A
- Features
- - · Lever Actuated, Retention Latches (Non-Wire Side) · Mating Flange, Retention Latches (Non-Wire Side) · Retention Latches (Non-Wire Side)
- Header orientation
- - · Vertical
- Insulation height
- 0.472\" (12.00mm) · 0.563\" (14.30mm)
- Mounting type
- Free Hanging (In-Line) · Through Hole
Shared specifications
- Color
- Orange
- Contact mating finish
- Tin
- Housing material
- Polyamide (PA66), Nylon 6/6
- Ingress protection
- -
- Material flammability rating
- UL94 V-0
- Number of levels
- 1
- Package
- Box
- Pitch
- 0.200\" (5.08mm)
- Screw size
- -
- Torque - screw
- -
- Voltage - IEC
- 630 V
- Voltage - UL
- 600 V
Variant comparison
| Parameter | 231-302/037-000 | 231-303/107-000 | 231-304/107-000 | 231-307/026-000 | 231-312/026-000 | 231-333/001-000 |
|---|---|---|---|---|---|---|
| Contact material | Copper Alloy | Copper Alloy | Copper Alloy | Copper Alloy | Copper Alloy | Electrolytic Copper |
| Contact tail length | - | - | - | - | - | 0.197\" (5.00mm) |
| Current - IEC | 16A | 16A | 16A | 16A | 16A | 12A |
| Current - UL | 15 A | 15 A | 15 A | 15 A | 15 A | 10 A |
| Features | Lever Actuated, Retention Latches (Non-Wire Side) | Mating Flange, Retention Latches (Non-Wire Side) | Mating Flange, Retention Latches (Non-Wire Side) | Retention Latches (Non-Wire Side) | Retention Latches (Non-Wire Side) | - |
| Header orientation | - | - | - | - | - | Vertical |
| Insulation height | 0.563\" (14.30mm) | 0.563\" (14.30mm) | 0.563\" (14.30mm) | 0.563\" (14.30mm) | 0.563\" (14.30mm) | 0.472\" (12.00mm) |
| Mounting type | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) | Through Hole |
Request a quote on any WAGO Corporation 2313 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the WAGO Corporation 2313 Series variants differ?
- WAGO Corporation 2313 Series part numbers differ by contact material, contact tail length, current - IEC and current - UL. Use the selection guide above to pick by contact material.
- How many WAGO Corporation 2313 Series part numbers are listed?
- 10 WAGO Corporation 2313 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for WAGO Corporation 2313 Series?
- Request a quote (RFQ) for any WAGO Corporation 2313 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
