264-701
WAGO Corporation
1.260\" (32.00mm)MiddleBulk
Ref. price$2.36
Lead time on requestGet quote ›
WAGO Corporation 2647 Series
8 variants · WAGO Corporation
About the WAGO Corporation 2647 Series
The WAGO Corporation 2647 Series series groups 8 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common material flammability rating of UL94 V-0, number of levels of 1 and stripping length of 8mm ~ 9mm. Variants differ by package, positions and terminal - width, so you can match the exact package your application requires using the selection guide below. All listed WAGO Corporation 2647 Series part numbers are active and orderable.
Select a variant by
- Package
- Box · Bulk
- Positions
- 2 · 4
- Terminal - width
- 6.0mm · 10.0mm
- Type
- Feed Through · Ground, Earth · Middle
- Voltage - IEC
- 800 V · 800V
- Color
- Blue · Green, Yellow · Orange
- Housing color
- Gray · Green, Yellow
- Length
- 1.260\" (32.00mm) · 1.496\" (38.00mm) · 1.831\" (46.51mm)
Shared specifications
- Material flammability rating
- UL94 V-0
- Number of levels
- 1
- Stripping length
- 8mm ~ 9mm
- Termination style
- Push In, Spring
- Wire gauge or range - AWG
- 12-28 AWG
- Wire gauge or range - mm2
- 0.08-2.5mm²
Variant comparison
| Parameter | 264-701 | 264-704 | 264-711 | 264-716 | 264-724 | 264-727 |
|---|---|---|---|---|---|---|
| Package | Bulk | Box | Bulk | Box | Box | Box |
| Positions | 2 | 2 | 2 | 2 | 4 | 4 |
| Terminal - width | 6.0mm | 6.0mm | 6.0mm | 6.0mm | 10.0mm | 10.0mm |
| Type | Middle | Feed Through | Middle | Feed Through | Feed Through | Ground, Earth |
| Voltage - IEC | 800 V | 800V | 800 V | 800V | 800V | — |
| Color | — | Blue | — | Orange | Blue | Green, Yellow |
| Housing color | Gray | — | Gray | — | — | — |
| Length | 1.260\" (32.00mm) | — | 1.496\" (38.00mm) | — | — | — |
Request a quote on any WAGO Corporation 2647 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the WAGO Corporation 2647 Series variants differ?
- WAGO Corporation 2647 Series part numbers differ by package, positions, terminal - width and type. Use the selection guide above to pick by package.
- How many WAGO Corporation 2647 Series part numbers are listed?
- 8 WAGO Corporation 2647 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for WAGO Corporation 2647 Series?
- Request a quote (RFQ) for any WAGO Corporation 2647 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
