WAGO Corporation 7342 Series

5 variants · WAGO Corporation

About the WAGO Corporation 7342 Series

The WAGO Corporation 7342 Series series groups 5 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common color of Orange, contact mating finish of Tin and current - IEC of 10A. Variants differ by contact material, contact tail length and features, so you can match the exact contact material your application requires using the selection guide below. All listed WAGO Corporation 7342 Series part numbers are active and orderable.

Select a variant by

Contact material: Copper Alloy · Electrolytic Copper
Contact tail length: - · 0.150\" (3.81mm) · 0.177\" (4.50mm)
Features: - · Retention Latches (Non-Wire Side)
Header orientation: - · 90°, Right Angle · Vertical
Insulation height: 0.406\" (10.31mm) · 0.528\" (13.40mm) · 1.122\" (28.50mm)
Mounting type: Free Hanging (In-Line) · Through Hole
Plug wire entry: - · 180°
Positions: 2 · 3 · 4 · 8

Shared specifications

Color: Orange
Contact mating finish: Tin
Current - IEC: 10A
Current - UL: 10 A
Housing material: Polyamide (PA66), Nylon 6/6
Ingress protection: -
Material flammability rating: UL94 V-0
Number of levels: 1
Operating temperature: -60°C ~ 100°C
Package: Box
Pitch: 0.150\" (3.81mm)
Screw size: -

Variant comparison

Parameter	734-202	734-203	734-208	734-234	734-263
Contact material	Copper Alloy	Copper Alloy	Copper Alloy	Electrolytic Copper	Electrolytic Copper
Contact tail length	-	-	-	0.177\" (4.50mm)	0.150\" (3.81mm)
Features	Retention Latches (Non-Wire Side)	Retention Latches (Non-Wire Side)	Retention Latches (Non-Wire Side)	-	-
Header orientation	-	-	-	Vertical	90°, Right Angle
Insulation height	0.528\" (13.40mm)	0.528\" (13.40mm)	0.528\" (13.40mm)	0.406\" (10.31mm)	1.122\" (28.50mm)
Mounting type	Free Hanging (In-Line)	Free Hanging (In-Line)	Free Hanging (In-Line)	Through Hole	Through Hole
Plug wire entry	180°	180°	180°	-	-
Positions	2	3	8	4	3

Request a quote on any WAGO Corporation 7342 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
