JST B9PS Series

2 variants · JST

About the JST JST B9PS Series series

The JST JST B9PS Series series groups 2 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common connector type of Header, contact finish - mating of Tin and contact finish - post of Tin. Variants differ by operating temperature, so you can match the exact operating temperature your application requires using the selection guide below. All listed JST B9PS Series part numbers are active and orderable.

Select a variant by

Operating temperature
-25°C ~ 85°C · -25°C~85°C

Variant comparison

ParameterB9PS-VHB9PS-VH(LF)(SN)
Operating temperature-25°C ~ 85°C-25°C~85°C

Shared specifications

Connector type
Header
Contact finish - mating
Tin
Contact finish - post
Tin
Contact length - mating
0.303\" (7.70mm)
Contact length - post
0.142\" (3.60mm)
Contact material
Brass
Contact shape
Square
Current rating
10A
Fastening type
Locking Ramp
Gender
Male Pin
Insulation color
Natural
Insulation height
0.335\" (8.51mm)

Request a quote on any JST B9PS Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.

Frequently asked questions

How do the JST JST B9PS Series variants differ?
JST B9PS Series part numbers differ by operating temperature. Use the selection guide above to pick by operating temperature.
How many JST JST B9PS Series part numbers are listed?
2 JST JST B9PS Series part numbers are listed, each with specifications and a datasheet where available.
How do I get pricing and lead time for JST JST B9PS Series?
Request a quote (RFQ) for any JST B9PS Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.

All variants

B9PS-VH
Molex VH series B9PS-VH, Board to Cable/Wire, Header, Male Pin, 9 Positions, 1 Row, 0.156" (3.96mm) Pitch, Through Hole, Right Angle, Solder, Tin Mating and Post, 10A, 250V, Locking Ramp, Shrouded - 1 Wall, UL94 V-0, -25°C to 85°C, Bulk.

Style: Board to Cable/Wire · Series: VH · Package: Bulk · Shrouding: Shrouded - 1 Wall · Termination: Solder · Gender: Male Pin · Contact shape: Square · Mounting type: Through Hole, Right Angle · Connector type: Header · Fastening type: Locking Ramp · Rows: 1 · Pitch: 0.156\" (3.96mm) · Voltage rating: 250V · Contact material: Brass · Insulation color: Natural · Insulation height: 0.335\" (8.51mm) · Insulation material: Polyamide (PA66), Nylon 6/6 · Positions: 9 · Contact finish - post: Tin · Contact length - post: 0.142\" (3.60mm) · Current rating: 10A · Operating temperature: -25°C ~ 85°C · Contact finish - mating: Tin · Contact length - mating: 0.303\" (7.70mm) · Material flammability rating: UL94 V-0

RFQ
B9PS-VH(LF)(SN)
JST VH series B9PS-VH(LF)(SN), 9-position single-row right-angle through-hole header, tin-plated brass contacts, 0.156" (3.96 mm) pitch, 10 A per circuit at 250 V, shrouded 1-wall with locking ramp, UL94 V-0 PA66 insulator, -25°C to 85°C, solder termination, bulk package.

Style: Board to Cable/Wire · Series: VH · Package: Bulk · Shrouding: Shrouded - 1 Wall · Termination: Solder · Gender: Male Pin · Contact shape: Square · Mounting type: Through Hole, Right Angle · Connector type: Header · Fastening type: Locking Ramp · Rows: 1 · Pitch: 0.156\" (3.96mm) · Voltage rating: 250V · Contact material: Brass · Insulation color: Natural · Insulation height: 0.335\" (8.51mm) · Insulation material: Polyamide (PA66), Nylon 6/6 · Positions: 9 · Contact finish - post: Tin · Contact length - post: 0.142\" (3.60mm) · Current rating: 10A · Operating temperature: -25°C~85°C · Contact finish - mating: Tin · Contact length - mating: 0.303\" (7.70mm) · Material flammability rating: UL94 V-0

RFQ
