JST — Pin Headers

JST Pin Headers — 46 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

title
22P-JED · B02B-JWPF-SK-R(LF)(SN) · B02B-PASK-1 · B02B-PASK-1(LF)(SN)
Base Product Number
B02B-JWP · B02B-PAS · B02B-PNI · B02B-WPJ
Insulation Height
0.209" (5.30mm) · 0.654" (16.61mm) · 0.303" (7.70mm) · 0.402" (10.20mm)
Mated Stacking Heights
21mm · 9.9mm, 14.7mm, 14.9mm · 12.25mm · 25.3mm
Number of Positions
22 · 2 · 3 · 4
Contact Length - Post
0.079" (2.00mm) · 0.130" (3.30mm) · 0.118" (3.00mm) · 0.134" (3.40mm)
Pitch - Mating
0.049" (1.25mm) · 0.079" (2.00mm) · 0.197" (5.00mm) · 0.098" (2.50mm)
Row Spacing - Mating
0.079" (2.00mm) · - · 0.156" (3.96mm) · 0.326" (8.28mm)
