Card-Edge Connectors

About Card-Edge Connectors

Card-edge connectors mate directly to the gold-finger pads of a PCB, eliminating the need for a separate cable or header. Common configurations include single-row, dual-row, and straddle-mount styles in pitches from 1.27 mm to 3.96 mm, with current ratings and contact plating that should be matched to the application's signal type and mating cycle count.
