Molex CLIK-Mate 213227 series, receptacle, 8 circuits, dual-row, 1.50mm pitch, SMT, gold mating finish 30.0µinch, latch holder, pick-and-place, solder retention, UL94 V-0, -40°C ~ 105°C
| Parameter | Value |
|---|---|
| Series | CLIK-Mate 213227 |
| Type | Forked |
| Mounting | Surface Mount |
| Connector type | Receptacle |
| Fastening type | Latch Holder |
| Voltage rating | 100VAC/DC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Natural |
| Insulation height | 0.346\" (8.80mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Features | Pick and Place, Solder Retention |
| Termination | Solder |
| Rows | 2 |
| Pitch | 0.059\" (1.50mm) |
| Positions | 8 |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 39.4µin (1.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The tin post finish (39.4 µinch) is standard for solder joint compatibility.
The part includes pick-and-place features and solder retention, meaning it is designed for automated surface-mount assembly. This is a practical detail if your line runs high-volume SMT and you want to avoid secondary hand-soldering operations.
The current rating is listed as 'Varies by Wire Gauge' — the actual current capacity depends on the wire size used in the mating cable assembly and the temperature rise in the application. For a given wire gauge, refer to the Molex CLIK-Mate application note for derating curves.
