Board-to-Cable Receptacle for Dense Wire Harnesses
SMT Termination with Solder Retention
Mating Half and Fit Notes
The latch holder engages with the plug's locking ramp, keyed so it can't go in wrong.
Molex 2132271011 CLIK-Mate 1.5 mm Receptacle, 10-Circuit
MPN2132271011
Active
Molex CLIK-Mate 213227 series, 2132271011, 1.50 mm pitch, 10-position dual-row surface-mount receptacle with gold-plated contacts and latch holder, rated 100 VAC/DC, -40°C to 105°C.
$2.7600Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesCLIK-Mate 213227
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | CLIK-Mate 213227 |
| Type | Forked |
| Mounting | Surface Mount |
| Connector type | Receptacle |
| Fastening type | Latch Holder |
| Voltage rating | 100VAC/DC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.346\" (8.80mm) |
| Insulation material | Polyamide (PA), Nylon |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Pick and Place, Solder Retention |
| Termination | Solder |
| Rows | 2 |
| Pitch | 0.059\" (1.50mm) |
| Positions | 10 |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 39.4µin (1.00µm) |
| Contact finish thickness - mating | 3.94µin (0.100µm) |
Product details
Frequently asked questions
What is the mating connector for 2132271011?
It mates with a CLIK-Mate 1.50 mm pitch plug housing (e.g., Molex 213228 series) and the corresponding crimp terminals. The latch holder on this receptacle locks with the plug's ramp for a vibration-resistant connection.
